Zirconia Ceramic Cylinder
Product Details
Product Introduction:
Its virtually contamination-free character makes it an ideal solution for a variety of applications that demand minimal contamination, including, but not limited to, nano materials, pharmaceutical, food, chemical, battery, ink, toner, dielectric, solar cell, semiconductor, etc.
Specification:
|
Items |
Unit |
Specification |
|
Composition |
wt% |
94.8% ZrO2 |
|
Specific Density |
g/cm3 |
>6.02 |
|
Hardness |
Mohs |
>9.0 |
|
Elastic modulus |
GPa |
200 |
|
Thermal Conductivity |
W/m.K |
3 |
|
Crushing Load |
KN |
~ 20 |
|
Fracture Toughness |
MPa*m1/2 |
9 |
|
Grain size |
um |
0.5 |
|
Thermal expansion |
1x10 -6 / °C |
9.6 |
Available size: 3*3, 5*5, 7*7, 10*10, 12.7*12.7, 15*15, 20*20mm
Advantages:
|
1. |
Highly cost-effective, low wear and long lifetime: YSZ milling/grinding material is the most durable and efficient media for ball milling of ceramic materials. Due to its ultra-low wear loss, its operational cost can be lower; |
|
2. |
High specific gravity, high efficiency, which saves processing time; |
|
3. |
Highly resistant to acid and solvents. |
Appliacation:
Production Details:
● Inner Structure:
● Size Distribution:
|
Product name: |
Yttria stabilized zirconia bead |
Size: |
Φ0.3mm |
|
|
100pcs test result by selected random (unit: mm) |
||||
|
0.28 |
0.29 |
0.3 |
0.31 |
0.32 |
|
0.28 |
0.29 |
0.3 |
0.31 |
0.32 |
|
0.28 |
0.29 |
0.3 |
0.31 |
0.32 |
|
0.28 |
0.29 |
0.3 |
0.31 |
0.32 |
|
0.29 |
0.29 |
0.31 |
0.31 |
0.32 |
|
0.29 |
0.3 |
0.31 |
0.31 |
0.32 |
|
0.29 |
0.3 |
0.31 |
0.31 |
0.32 |
|
0.29 |
0.3 |
0.31 |
0.31 |
0.33 |
|
0.29 |
0.3 |
0.31 |
0.31 |
0.33 |
|
0.29 |
0.3 |
0.31 |
0.31 |
0.33 |
|
0.29 |
0.3 |
0.31 |
0.32 |
0.33 |
|
0.29 |
0.3 |
0.31 |
0.32 |
0.33 |
|
0.29 |
0.3 |
0.31 |
0.32 |
0.33 |
|
0.29 |
0.3 |
0.31 |
0.32 |
0.33 |
|
0.29 |
0.3 |
0.31 |
0.32 |
0.33 |
|
0.29 |
0.3 |
0.31 |
0.32 |
0.33 |
|
0.29 |
0.3 |
0.31 |
0.32 |
0.34 |
|
0.29 |
0.3 |
0.31 |
0.32 |
0.34 |
|
0.29 |
0.3 |
0.3 |
0.3 |
0.36 |
|
0.29 |
0.3 |
0.3 |
0.3 |
0.3 |
