95% Zirconia Bead

Name: 95% Zirconia Bead
Brand: Kingda
SKU: 149474610

Kingda Y-TZP 95% Zirconia Bead consists of yttrium stabilized zirconium oxide. Yttrium Stabilized Zirconia (Y-TZP) is the strongest ceramic material we offer. Y-TZP is a purely tetragonal phase, fine grain material.Mainly used for ultra-fine grinding and dispersing of "zero pollution" and high viscosity and high hardness materials.

Product Details

Product Introduction:

Kingda Y-TZP 95% Zirconia Bead consists of yttrium stabilized zirconium oxide. Yttrium Stabilized Zirconia (Y-TZP) is the strongest ceramic material we offer. Y-TZP is a purely tetragonal phase, fine grain material.

Chemical Composition:

Composition	ZrO₂	Y₂O₃	Other
Content %	94.8±0.2	5.1±0.1	0.1%

Physical Properties:

Specific Gravity g/cm³	Bulk Density g/cm³	Hardness Hv	Fracture Toughness MPam^1-2	Crushing Load KN (Φ2.0mm)	Grain size um	Wear loss (%)	Sphericity (%)
≥6.02	≥ 3.70	≥1250	9	≥20	≤0.5	≤0.08	≥98

Ball Sizes:

Size (mm)	Size (mm)	Size (mm)	Size (mm)	Size (mm)
Φ0.08-0.12	Φ0.12-0.18	Φ0.18-0.22	Φ0.22-0.28	Φ0.28-0.35
Φ0.3-0.4	Φ0.4-0.6	Φ0.6-0.8	Φ0.8-1.0	Φ1.0-1.2
Φ1.2-1.4	Φ1.4-1.6	Φ1.6-1.8	Φ1.8-2.0	2.0-2.2
Φ2.2-2.4	Φ2.4-2.6	Φ2.6-2.8	Φ2.8-3.0	Φ3.0-3.2
Φ3.2-3.5	Φ4	Φ5	Φ6	Φ7
Φ8	Φ10	Φ12	Φ15	Φ17
Φ20	Φ25	Φ30	Φ40	Φ50

Applications:

It is widely used for grinding, dispersing and polishing as following: inkjets inks, electronic slurries, raw material of battery, screen printing inks, coating, painting, pigment, ceramic and cosmetic, jewelry and other nanoparticles products.

Production Details:

_DSC8556 _DSC8518 _DSC8546

Display Cabinet:

IMG_20210316_141023

IMG_20210316_152532

Main advantage

1. The production of ceramic grinding media balls is one of China's largest industries.

2. SGS, ROHS certification, and ISO 9001 strict quality control system

3. Competence, Sincerity, Focus, Honesty, Continuous Strive for Improvement, Mutual Glory.

4. Imported Australian high-quality raw materials.

5. Fast arrival and secure packaging

Features:

Long lifespan: Zirconium silicate beads have a lifespan six times longer than glass beads and 30 times longer than glass beads.

High efficiency: around a six-fold increase over glass beads and a two-fold increase over zirconium silicate beads.

High-solid-phase pastes with high viscosities and hardness are particularly well suited for grinding and dispersion; they also pair well with high input energies and high shear machine sanding because of their excellent wear resistance and fracture toughness.

Applicable industry:
95% Zirconia Bead is suitable for milling and dispersing high viscosity pastes such as paper making, textile, dyeing, screen printing inks,offset inks, CaCO3, metal minerals;and high purity products ,such as pharmaceutical and foodstuff.

FAQ:

What is ceramic grinding media?	Ceramic Grinding media, as the name suggests, is used for particle size reduction by facilitating interaction between the media and the material in a closed space. CUMITUFF-90 (90% alumina) products are used for wear resistant applications.Please come in and have a look at our best sellers.
What is the hardest grinding media?	Tungsten carbide media has the highest specific gravity. It is the hardest and densest known grinding media.We know the best offer will be accepted. Please contact us here!
What is the density of ceramic grinding media?	The density of the steel ball is about 7.6-7.8g/cm3, and the density of the current ceramic grinding body is generally 3.6-3.8g/cm3, and the density is reduced by about half.We have an exclusive offer for our members.
