Alumina Grinding Media
Product Details
Product Introduction:
Kingda polished alumina ceramic jars are used whenever small quantity of samples needed to be grinded. Each jar set includes grinding jar, lid, rubber sealing gasket and different sizes of mixed alumina ceramic grinding balls. It is best container for grinding rare earth materials, precious metals, medium and low ceramic capacitors, NTC, PTC piezoelectric ceramic and lithium cobalt oxide, lithium manganese oxide powder.
Physical Parameters:
Composition % | Specific Gravity g/cm3 | Hardness Mho’s | Bending strength (Mpa) | Water absorption rate % |
Al2O3 ≥ 99 | ≥3.8 | 9 | > 350 | ≤0.005 |
Specification Parameters:
Volume of Jar | Inner Diameter | External Diameter | Inner Depth (mm) | Height of without lid (mm) | Total Height |
50ml | 38 | 55 | 52 | 60 | 67 |
100ml | 50 | 65 | 58 | 66 | 75 |
250ml | 74 | 92 | 70 | 78 | 88 |
500ml | 84 | 100 | 100 | 108 | 118 |
1L | 108 | 128 | 128 | 138 | 148 |
2L | 138 | 158 | 140 | 150 | 162 |
3L | 138 | 158 | 198 | 208 | 220 |
Features:
1. High cost-effective, low wear and long lifetime
2. High specific gravity, high efficiency
3. Highly wear resistant to acid and solvents
4. High mechanical strength, good toughness, impact resistance, no broken beads
5. Mainly used for lab planetary ball mill machine
Production Details:
Usage:
